Over charge detection voltage : 4.25V ± 25mV

Over charge release voltage : 4.10V ± 50mV

Over charge detection delay Time : 1.0s ±  0.3s

Cell-balance detection voltage : 4.20V ±  25mV

Cell-balance release voltage : 4.19V +25mV /-50mV

Cell-balance current : 40mA ±  4mA

Over discharge detection voltage : 2.5V ±  62.5mV

Over discharge release voltage : 3V ± 75mV

Over discharge detection delay Time : 119ms ±   36ms

Charging overcurrent detection current : 20A ± 12A

Charging overcurrent detection delay Time : 8ms ± 3ms

Discharge overcurrent detection current : 40A ± 8A

Discharge overcurrent detection delay Time : 9.9ms ±  3ms

Overtemperature detection temperature : 70°C ± 5 °C

Overtemperature release temperature : 60 °C +5 / -10°C

Consumption current (Operating mode) : Max u30A

Over charge detection voltage : 4.25V ± 25mV

Over charge release voltage : 4.10V ± 50mV

Over charge detection delay Time : 1.0s ±  0.3s

Cell-balance detection voltage : 4.20V ±  25mV

Cell-balance release voltage : 4.19V +25mV /-50mV

Cell-balance current : 40mA ±  4mA

Over discharge detection voltage : 2.5V ±  62.5mV

Over discharge release voltage : 3V ± 75mV

Over discharge detection delay Time : 119ms ±   36ms

Charging overcurrent detection current : 20A ± 12A

Charging overcurrent detection delay Time : 8ms ± 3ms

Discharge overcurrent detection current : 40A ± 8A

Discharge overcurrent detection delay Time : 9.9ms ±  3ms

Overtemperature detection temperature : 70°C ± 5 °C

Overtemperature release temperature : 60 °C +5 / -10°C

Consumption current (Operating mode) : Max u30A
